Gmp General Machine Products 89916 Gentle Air Whisper With Clutch
Gmp General Machine Products 89916 Gentle Air Whisper With Clutch
P/N 89916 Gmp General Machine Products Gentle Air Whisper With Clutch Weight 12 Lbs (5.4Kgs)
Includes: Gentle Air Cable Blowing Machine (2) 9V Lithium Batteries Tube Collet And Clamp Assembly For (1) Tube Size Of Your Choice Cable Seal Collet Assembly For (1) Cable Size Of Your Choice Toolkit Travel Bag Manual
Specifications Cable Diameter: 0.039" To 0.118" (1.0 To 3.0Mm) Tube Size (Outside Dia): (Od) 0.158" To 0.275" (4 To 7Mm) Cable Speed (Adjustable): 0-300 Ft/Min (0-90M/Min) Max Air Pressure: 220 Psi (15 Bar) Power Requirement: Variable Speed Drill Width: 8.1 In. (206Mm) Length: 9.7 In. (246Mm) Height: 8.5 In. (216Mm)
The Gentle Air Uses Compressed Air To Install The Fiber. Coupled With The Driven Roller Is A Precision Clutch That You Can Dial In Your Custom Torque From Zero To Infinity. The Rollers, Powered By Most Types Of Cordless Drills (Not Included), Control The Blown Fiber As It Is Propelled Into The Microduct. An Electronic Monitoring System Provides Read-Outs Of Speed And Distance. The Design Of The Gentle Air Provides For Quick And Easy Component Changes For Different Cable Or Duct Sizes. Its Compact Size And Portable Maneuverability Make The Gentle Air Ideally Suited For External Or In-Building Use.
The Gentle Air Uses Compressed Air To Install The Cable. The Rollers, Powered By Most Types Of Cordless Drills (Not Included), Control The Microfiber As It Is Propelled Into The Microduct.
We Suggest Using A Variable Speed Drill With An Adjustable Torque Setting Powered By An 18-20 Volt Battery. We Further Suggest A Brush-Less Type Drill Manufactured By An Industrial-Grade Manufacturer.
Main Features Installs Cable Diameters Of 0.039" To 0.118" (1.0 To 3.0Mm) Digital Cable Speed And Length Monitoring Accommodates Microduct Sizes Of 4 To 7Mm (Od) Integral Air Valve And Pressure Gauge Uses A Fully Adjustable Precision Clutch For Torque Control Low Maintenance Uses Most Variable Speed Drills As A Power Source Ideal For Smaller Jobs Where A Bigger Machine Is Simply Too Much Lightweight, Durable Construction With Precision Machined Parts Travel Bag Included Single Person Operation
Gmp General Machine Products 89916 Gentle Air Whisper With Clutch
P/N 89916 Gmp General Machine Products Gentle Air Whisper With Clutch Weight 12 Lbs (5.4Kgs)
Includes: Gentle Air Cable Blowing Machine (2) 9V Lithium Batteries Tube Collet And Clamp Assembly For (1) Tube Size Of Your Choice Cable Seal Collet Assembly For (1) Cable Size Of Your Choice Toolkit Travel Bag Manual
Specifications Cable Diameter: 0.039" To 0.118" (1.0 To 3.0Mm) Tube Size (Outside Dia): (Od) 0.158" To 0.275" (4 To 7Mm) Cable Speed (Adjustable): 0-300 Ft/Min (0-90M/Min) Max Air Pressure: 220 Psi (15 Bar) Power Requirement: Variable Speed Drill Width: 8.1 In. (206Mm) Length: 9.7 In. (246Mm) Height: 8.5 In. (216Mm)
The Gentle Air Uses Compressed Air To Install The Fiber. Coupled With The Driven Roller Is A Precision Clutch That You Can Dial In Your Custom Torque From Zero To Infinity. The Rollers, Powered By Most Types Of Cordless Drills (Not Included), Control The Blown Fiber As It Is Propelled Into The Microduct. An Electronic Monitoring System Provides Read-Outs Of Speed And Distance. The Design Of The Gentle Air Provides For Quick And Easy Component Changes For Different Cable Or Duct Sizes. Its Compact Size And Portable Maneuverability Make The Gentle Air Ideally Suited For External Or In-Building Use.
The Gentle Air Uses Compressed Air To Install The Cable. The Rollers, Powered By Most Types Of Cordless Drills (Not Included), Control The Microfiber As It Is Propelled Into The Microduct.
We Suggest Using A Variable Speed Drill With An Adjustable Torque Setting Powered By An 18-20 Volt Battery. We Further Suggest A Brush-Less Type Drill Manufactured By An Industrial-Grade Manufacturer.
Main Features Installs Cable Diameters Of 0.039" To 0.118" (1.0 To 3.0Mm) Digital Cable Speed And Length Monitoring Accommodates Microduct Sizes Of 4 To 7Mm (Od) Integral Air Valve And Pressure Gauge Uses A Fully Adjustable Precision Clutch For Torque Control Low Maintenance Uses Most Variable Speed Drills As A Power Source Ideal For Smaller Jobs Where A Bigger Machine Is Simply Too Much Lightweight, Durable Construction With Precision Machined Parts Travel Bag Included Single Person Operation
