INNO VIEW 5 PRO KIT CORE ALIGNMENT(DACAS) FUSION SPLICER KIT WITH CLOUD BASE
Available*
Item # 53960805
Model # VIEW 5 PRO KIT
$7,868.00
financing available. Learn MoreModel:
* Notes on Availability:
(Images may not be of the actual item being sold.)
- Product Description
- You Might Also like
- Recently Viewed
Generic
Class
Group
Type
Manufacturer
LOT
FUSION SPL
Fiber Optic Products
Fusion and Mechanical Splicing
Fiber Fusion Splicer
INNO Instrument
Fusion Splicers
Warning: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.govProduct Description
INNO VIEW 5 PRO
SMART CORE ALIGNMENT FUSION SPLICER W/ A CLOUD-BASED OPERATION & MANAGEMENT SYSTEM
·Built-in IoT Module for Mobile Data Communication ·Web-based, Real-time Operation System ·Core Alignment Splicing with DACAS Profiling System ·The Highest Magnification and Resolution ·5” Color LCD Touch Screen ·Double Tapping ( Zoom in & Out ) ·Fast Heating Time ·Detachable SOC Holder and Heating Oven ·3 Bright LEDs for Dark Environment ·User Friendliest Interface with Built-in Videos
Description VIEW5 PRO, a core-alignment splicer with the world’s highest fiber image magnification rate, is the most proficient fusion splicer in the market. VIEW5 PRO’s 5 inch high-resolution color LCD touch screen with user-friendly intuitive GUI (Graphic User Interface) offers large and clear fiber images to users. By double-tapping the screen, users can Zoom In & Out the image to the world’s highest magnification of 520x. The fusion splicer is equipped with built-in IoT module that connects to the INNO's View Pro Cloud Management System for real-time operation and management online. This innovative cloud-based solution is designed to create the most advanced and yet most uncomplicated splicing and work experiences ever. View Pro Management System View Pro Management System is an integrated cloud-based software platform for INNO’s splicers. This innovative web-based application allows both technicians and managers of the splicers to maximize the use of its assets and to achieve the highest work efficiency. Real-time communications with tiered access rights and options to manage job orders, manage splicing machines, and send/receive reports are only a small part of the innovative work processes offered by the View Pro.
Specifications Model VIEW5 PRO Alignment Method Core alignment Number of fiber Single Applicable fibers SM (ITU-T G.652&G.657) / MM (ITU-T G.651) / DS (ITU-T G.653) / NZDS (ITU-T G.655) Cladding Diameter 80 ~ 150ěm Clevaed Length 5 ~ 16mm Typical Splice Loss*1 SM: 0.02dB / MM:0.01dB / DS:0.04dB / NZDS: 0.04dB / G.657: 0.02dB Return Loss >> 60dB Estimated Splice Loss Available Splice Time*2 Quick mode : 9 sec (Avg.) / SM Auto mode : 11 sec (Avg.) Splice Mode Max 128 modes Heating Sleeve 20 ~ 60mm Heating Time*3 Quick mode: 15s (Avg.) Heating Mode Max 32 modes Tension Test 1.96 ~ 2.25N Dimension 149W x 177D x 151H mm (including rubber bumper) / 130W x 166D x 140H mm (excluding rubber bumper) Weight 2.21kg (with battery) / 1.85kg (without battery) White LED 3 White LEDs Monitor 5.0” Color LCD display, Full touch screen Fiber View X, Y, XY, X/Y Magnification 320 ~ 520x Results Storage 10,000 Splice data / 10,000 Splice image Power Supply AC Input 100 ~ 240V, DC Input 9 ~ 14V Terminal USB Type C / Nano SIM Battery Capacity*4 5200mAh Battery Capacity, Typical 200 Cycles (Splice+Heat) Electrode Life*5 5500 arcs discharges
Package VIEW5 PRO Fusion Splicer Standard Accessories V12 Cleaver 1ea FH-45 Fiber Holder 1set FH-SOC-R SOC Holder 1ea HTS-SOC-02 SOC Heater Cover 1ea JS-180300 AC Adapter 1ea CG-22 Cooling Tray 1ea E-50 Electrode 1set LBT-52 Battery Pack 1ea ACC-25 Power Cable 1ea USB-7P USB Cable 1ea ICC-55 Carrying Case 1ea IWS-06 Work Tray 1ea WTB-01 Work Tray Bolt (M6*8) 1ea WTB-02 Work Tray Bolt (M6*14) 1ea ST-01 Shoulder Strap 2ea Quick Reference 1ea
OPTIONAL ACCESSORIES TK02-AP01 Alcohol pump 1ea TK02-MP01 Stripper 1ea CJ-11 Cigarette Lighter Cable 1ea EG-18 Electrode Grinder 1ea PS-60S Heating sleeve(60mm) 1pack(100ea)
SHIPPING DIMENSIONS 28"X16"X13" SHIPPING WEIGHT 24 LBS
