GREENLEE DVM-80UVM DIGIVOLT DIGITAL PHASING VOLTMETER 783310628293/52068909
GREENLEE DVM-80UVM DIGIVOLT DIGITAL PHASING VOLTMETER 783310628293/52068909
Measures voltage and performs phasing operations from 50V to 40kV and up to 80kV with add-on resistors Provides consistent high accuracy voltage measurements - within 1% of reading Auto-ranging - no settings required Capacitive Test Point and Peak Hold modes Auto-shutoff and low battery indicator features Versatile for overhead and underground applications
Specifications Sub Brand HDE Type Voltmeter Model DVM-80UVM Voltage Rating 5V - 40kV up to 80kV with add-on resistors Accuracy Within 1% of reading +/- 3 counts (line-to-ground and line-to-line measurements); Within 2% of reading +/- 3 counts (line-to-ground & line-to-line measurements) with add-on resistors Display LCD indicates 3.5 digits Operating Temperature -20°F to +140°F (–29°C to +60°C) Dimensions 5" W x 4.25" L x 1.38" H (13 cm x 11 cm x 3.5 cm) Frequency Rating 25 - 1000Hz AC/DC Included DVM-80UVM Voltmeter, 025-OLPS-5 Overhead Brass Hook Probes (2), CS-DVM Case
GREENLEE DVM-80UVM DIGIVOLT DIGITAL PHASING VOLTMETER 783310628293/52068909
Measures voltage and performs phasing operations from 50V to 40kV and up to 80kV with add-on resistors Provides consistent high accuracy voltage measurements - within 1% of reading Auto-ranging - no settings required Capacitive Test Point and Peak Hold modes Auto-shutoff and low battery indicator features Versatile for overhead and underground applications
Specifications Sub Brand HDE Type Voltmeter Model DVM-80UVM Voltage Rating 5V - 40kV up to 80kV with add-on resistors Accuracy Within 1% of reading +/- 3 counts (line-to-ground and line-to-line measurements); Within 2% of reading +/- 3 counts (line-to-ground & line-to-line measurements) with add-on resistors Display LCD indicates 3.5 digits Operating Temperature -20°F to +140°F (–29°C to +60°C) Dimensions 5" W x 4.25" L x 1.38" H (13 cm x 11 cm x 3.5 cm) Frequency Rating 25 - 1000Hz AC/DC Included DVM-80UVM Voltmeter, 025-OLPS-5 Overhead Brass Hook Probes (2), CS-DVM Case
