200/26 SEALPICFSF CABLE 1000/REEL PRICE PER 1000 FEET REEL NEW
Available*
Item # 55270000
Model # 200x26 awg PE89
$1,830.60
financing available. Learn More
* Notes on Availability:
(Images may not be of the actual item being sold.)
- Product Description
- You Might Also like
- Recently Viewed
Generic
Class
Group
Type
Manufacturer
LOT
CABLE
Wire and Cable
Filled- Flooded-Jelly
Sheilded
Superior Essex Inc
Warning: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.govProduct Description
200/26 SEALPICFSF CABLE 1000/REEL PRICE PER 1000 FEET REEL NEW
200/26 SEALPICFSF CABLE 1000/REEL PRICE PER 1000 FEET REEL NEW
200/26 SEALPICFSF CABLE 1000/REEL PRICE PER 1000 FEET REEL
SEALPIC-FSF cables are designed for direct burial or duct applications where protection from moisture is required and aluminum shielding is desired. SEALPIC-FSF may be used aerially, but must be attached to a support strand
Physical Description
CONDUCTORS: Solid annealed copper in 19, 22, 24 and 26 AWG. INSULATION: Conductors are dual insulated with an inner layer of foamed,natural polyolefin covered by an outer layer of solid, colored polyolefin. Theconductor insulation is color coded in accordance with industry standards. TWISTED PAIRS: Individual insulated conductors are twisted into pairs withvarying lay lengths to minimize crosstalk and specific color combinations toprovide pair identification. CORE ASSEMBLY: Cables of 25 pairs or less are assembled into a cylindricalcore. Cables larger than 25 pairs are assembled into units, which are then usedto assemble the core. Units are individually identifiable by color codedunit binders. FILLING COMPOUND: The core assembly is filled with an 80°C ETPRcompound, completely filling the interstices between the pairs and underthe core wrap. CORE WRAP: A non-hygroscopic, dielectric tape is applied overthe core assembly to provide thermal protection for the core.SHIELDING: A corrugated, copolymer coated, 8-mil aluminum tape is appliedlongitudinally with an overlap. The shield interfaces are flooded. JACKET: A black, linear low-density polyethylene jacket is applied overall. Thejacket provides a tough protective covering designed to withstandexposure to direct sunlight, atmospheric temperature changes and stressesexpected in standard installations. JACKET MARKINGS: Information such as manufacturer’s identification,pair count, AWG, product identification, sequential footage and a telephonehandset is printed at 2 ft. intervals on the cable jacket.
200/26 SEALPICFSF CABLE 1000/REEL PRICE PER 1000 FEET REEL NEW
200/26 SEALPICFSF CABLE 1000/REEL PRICE PER 1000 FEET REEL
SEALPIC-FSF cables are designed for direct burial or duct applications where protection from moisture is required and aluminum shielding is desired. SEALPIC-FSF may be used aerially, but must be attached to a support strand
Physical Description
CONDUCTORS: Solid annealed copper in 19, 22, 24 and 26 AWG. INSULATION: Conductors are dual insulated with an inner layer of foamed,natural polyolefin covered by an outer layer of solid, colored polyolefin. Theconductor insulation is color coded in accordance with industry standards. TWISTED PAIRS: Individual insulated conductors are twisted into pairs withvarying lay lengths to minimize crosstalk and specific color combinations toprovide pair identification. CORE ASSEMBLY: Cables of 25 pairs or less are assembled into a cylindricalcore. Cables larger than 25 pairs are assembled into units, which are then usedto assemble the core. Units are individually identifiable by color codedunit binders. FILLING COMPOUND: The core assembly is filled with an 80°C ETPRcompound, completely filling the interstices between the pairs and underthe core wrap. CORE WRAP: A non-hygroscopic, dielectric tape is applied overthe core assembly to provide thermal protection for the core.SHIELDING: A corrugated, copolymer coated, 8-mil aluminum tape is appliedlongitudinally with an overlap. The shield interfaces are flooded. JACKET: A black, linear low-density polyethylene jacket is applied overall. Thejacket provides a tough protective covering designed to withstandexposure to direct sunlight, atmospheric temperature changes and stressesexpected in standard installations. JACKET MARKINGS: Information such as manufacturer’s identification,pair count, AWG, product identification, sequential footage and a telephonehandset is printed at 2 ft. intervals on the cable jacket.
