TEMPO FI-100 KIT IDENTIFIER, FIBER KIT (FI-100) 783310033530 /52068188
Available*
Item # 79992804
Model # FI-100
$1,620.00
financing available. Learn More
* Notes on Availability:
(Images may not be of the actual item being sold.)
- Product Description
- You Might Also like
- Recently Viewed
Generic
Class
Group
Type
Manufacturer
LOT
IDENTIFIER
Fiber Optic Products
OTDR- Power Meter- Light Source- Idenitifiers- VFL
Fiber Identifiers- VFL
Tempo Communications, Inc.
Warning: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.govProduct Description
GREENLEE FI-100 KIT IDENTIFIER, FIBER KIT (FI-100) 783310033530 /52068188 NEW
DESCRIPTION: Low insertion loss.
Non-intrusive low insertion loss prevents alarm conditions.
Easy Operation
Identifies fiber with tone detect and a clear indication of signal transmission direction.
Versatile
Supports all common fibers including 250æm, 900æm, 2mm and 3mm and is able to sense light in bend insensitive fibers.
SPECIFICATIONS:
Dimensions : 196 X 30.5 X 27mm Identified Signal Type : 270Hz, 1kHz, 2kHz Identified Wave LengthRange : 800-1700nm Insertion Loss Maximum :
0.8dB (1310nm) 2.5dB (1550nm)
Insertion Loss Typical :
0.3dB (1310nm) 1.5dB (1550nm)
Operating Temperature : -10 to +60øC Signal Direction : LEFT AND RIGHT LED INDICATORS Signal Direction Test Range : -46 TO +10dBm (1310nm) Signal Power Test Range : -50 TO +10dBm (1550nm) Storage Temperature : -25 to +70øC Weight : 195g
CAT #: FI-100 KIT UPC #: 783310033530 /52068188
